OYI-ATB01C Desktop Box

Optic Fiber FTTH Box 1 Cores Type

OYI-ATB01C Desktop Box

OYI-ATB01C one ports terminal box is developed and produced by the company itself. The product’s performance meets the requirements of industry standards YD/T2150-2010. It is suitable for installing multiple types of modules and can be applied to the work area wiring subsystem to achieve dual-core fiber access and port output. It provides fiber fixing, stripping, splicing, and protection devices, and allows for a small amount of redundant fiber inventory, making it suitable for FTTD (fiber to the desktop) system applications. The box is made of high-quality ABS plastic through injection molding, making it anti-collision, flame retardant, and highly impact-resistant. It has good sealing and anti-aging properties, protecting the cable exit and serving as a screen. It can be installed on the wall.

Product Detail

FAQ

Product Tags

Product Features

1. IP-55 Protection level.

2. Integrated with cable termination and management rods.

3. Manage fibers in a reasonable fiber radius(30mm) condition.

4. High quality industrial anti-aging ABS plastic material.

5. Suitable for the wall mounted installation.

6. Suitable for FTTH indoor application.

7. 1 port cable entrance for drop cable or patch cable.

8. Fiber adapter can be installed in the rosette for patching.

9. UL94-V0 fire-retardant material can be customized as option.

10. Temperature: -40 ℃ to +85 ℃.

11. Humidity: ≤ 95% (+40 ℃).

12. Atmospheric pressure: 70KPa to 108KPa.

13. Box structure: The one-port desktop box consists mainly of the cover and the bottom box. The box structure is shown in the figure.

Specifications

Item No.	Description	Weight (g)	Size (mm)
OYI-ATB01C	For 1pc SC Simplex Adapter	25	915017
Material	ABS/ABS+PC
Colour	White or customer’s request
Waterproof	IP55

Applications

1. FTTX access system terminal link.

2. Widely used in FTTH access network.

3. Telecommunication networks.

4. CATV networks.

5. Data communications networks.

7. Local area networks.

The Installation Instruction of The Box

1. Wall installation.

1.1 According to the bottom box mounting hole distance on the wall to play two mounting holes, and knock into the plastic expansion sleeve.

1.2 Fix the box to the wall with M8 × 40 screws.

1.3 Check the installation of the box, qualified to cover the lid.

1.4 According to the construction requirements of the introduction of outdoor cable and FTTH drop cable.

2. Open the box.

2.1 Hands were holding the cover and the bottom box, a little hard to break out to open the box.

Optional Accessories

1. SC/UPC simplex Adapter for terminal box.

Parameters	SM			MM
Parameters	PC	UPC	APC	UPC
Operation Wavelength	1310&1550nm			850nm&1300nm
Insertion Loss (dB) Max	≤0.2	≤0.2	≤0.2	≤0.3
Return Loss (dB) Min	≥45	≥50	≥65	≥45
Repeatability Loss (dB)	≤0.2
Exchangeability Loss (dB)	≤0.2
Repeat Plug-Pull Times	＞1000
Operation Temperature (℃)	-20~85
Storage Temperature (℃)	-40~85

Packaging Information

1. Quantity: 20pcs/ Inner box, 200pcs/Outer box.

2. Carton Size: 49*49*27cm.

3. N. Weight: 20kg/Outer Carton.

4. G. Weight: 21kg/Outer Carton.

5. OEM service available for mass quantity, can print logo on cartons.

Inner Box

Outer Carton
