Steel Insulated Clevis
Hardware Products Overhead Line Fittings
Steel Insulated Clevis
Product Description
Insulated Clevis is a specialized type of clevis designed for use in electrical power distribution systems. It is constructed with insulating materials such as polymer or fiberglass, which encase the metal components of the clevis to prevent electrical conductivity are used to securely attach electrical conductors, such as power lines or cables, to insulators or other hardware on utility poles or structures. By isolating the conductor from the metal clevis, these components help minimize the risk of electrical faults or short circuits caused by accidental contact with the clevis. Spool Insulator Bracke are essential for maintaining the safety and reliability of power distribution networks.
Product Features
1. Material: Steel with Hot dip galvanized.
2. Secure Attachment: They are designed to securely attach electrical conductors to insulators or other hardware on utility poles or structures, ensuring reliable connection and support.
3. Corrosion Resistance: Service entrance clevis may feature corrosion-resistant coatings or materials to withstand exposure to outdoor elements and ensure long-lasting performance.
4. Compatibility: These are compatible with various sizes and types of electrical conductors, making them versatile for different applications in power distribution systems.
5. Safety: By isolating the conductor from the metal clevis, iron clamp help minimize the risk of electrical faults, short circuits, or injuries caused by accidental contact with the clevis.
6. Compliance: They may be designed and manufactured to meet industry standards and regulatory requirements for electrical insulation and safety.
Specifications
Other Size can be made as customers request.
Applications
Packaging Information
-
