Self-Locking Nylon Cable Ties
Hardware Products
Self-Locking Nylon Cable Ties
Product Features
1. Self-locking mechanism: When the tail end of the band is threaded through the head and tightened, internal teeth firmly grip the tail end, automatically locking it in place. Once secured, it cannot be released without cutting.
2. High tensile strength: Made from durable nylon 66 material, it offers strong tensile strength and impact resistance. It securely holds heavy items or large bundles.
High Versatility: Suitable for a wide range of applications from household to industrial use, including cable management, securing automotive parts, and temporary fastening at construction sites.
3. Weather Resistance: Black cable ties contain UV stabilizers, making them resistant to ultraviolet rays and suitable for outdoor use. White (natural) cable ties are primarily intended for indoor use.
4. Heat Resistance: Performance varies by product, but generally operates within a wide temperature range from -40°C to 85°C. Some products offer heat resistance up to 140°C for short periods.
5. Cost-Effective: Compared to metal cable ties offering equivalent strength, they are affordable and economical.
Specifications
| ITEM NUMBER & DESCRIPTION | Length | Width | BUNDDLE DIAMETER | TENSILE STRENG | BAGS/CTN | ||
|---|---|---|---|---|---|---|---|
| 100PCS/BAG | Inch | MM | MM | MM | LBS | KG | |
| 7.2X150 | 6.0" | 150 | 7.2 | 3-35 | 120 | 55 | 70 |
| 7.2X200 | 8.0" | 200 | 3-50 | 60 | |||
| 7.2X250 | 10" | 250 | 4-65 | 60 | |||
| 7.2X300 | 12" | 300 | 4--80 | 50 | |||
| 7.2X350 | 14" | 350 | 4-90 | 40 | |||
| 7.2X380 | 15" | 380 | 4--100 | 40 | |||
| 7.2X400 | 16" | 400 | 4-105 | 40 | |||
| 7.2X4S0 | 1.6 | 4SC | 4-105 | ||||
| 7.2X500 | 20" | 500 | 4-150 | 30 | |||
| 7.2X550 | 21.6" | 550 | 4--165 | 20 | |||
| 7.6X200 | 8.0" | 200 | 7.6 | 3-50 | 120 | 55 | 60 |
| 7.6X250 | 10" | 250 | 4-65 | 60 | |||
| 7.6X300 | 12" | 300 | 4--80 | 50 | |||
| 7.6X350 | 14" | 350 | 4--90 | 40 | |||
| 7.6X380 | 15 | 380 | 4--100 | 40 | |||
| 7.6X400 | 16" | 400 | 4-105 | 40 | |||
| 7.6X450 | 18" | 450 | 4-110 | 35 | |||
| 7.6X500 | 20" | 500 | 4-150 | 30 | |||
| 7.6X550 | 21.6" | 550 | 4-165 | 15 | |||
| 8.8X400 | 16" | 400 | 8.8 | 8-105 | 175 | 79.4 | 25 |
| 8.8X450 | 18" | 450 | 8-118 | 20 | |||
| 8.8X500 | 20" | 500 | 8-150 | 20 | |||
| 8.8X550 | 21.6" | 550 | 8-160 | 15 | |||
| 8.8X600 | 23.6" | 600 | 8-170 | 15 | |||
| 8.8X650 | 25.6" | 650 | 8-185 | 15 | |||
| 8.8X710 | 28.3" | 710 | 8-195 | 15 | |||
| 8.8X760 | 29.9" | 760 | 10-210 | 15 | |||
| 8.8X800 | 31.5" | 800 | 10-230 | 15 | |||
| 8.8X920 | 36.2" | 920 | Id-265 | 15 | |||
| 8.8X1000 | 43.3" | 1000 | 10--335 | 15 | |||
| 8.8X1200 | 47.2" | 1200 | 10-370 | 15 | |||
| 10X650 | 25.6" | 650 | 10 | 8-185 | 198 | 90 | 10 |
| 12X500 | 20" | 500 | 12 | 8-150 | 251 | 114 | 10 |
| 12X550 | 21.6" | 550 | 8-160 | 10 | |||
| 12X600 | 23.6" | 600 | 8-170 | 10 | |||
| 12X650 | 25.6" | 650 | 8-185 | 10 | |||
| 12X700 | 28.3" | 700 | 8-195 | 10 | |||
| 12X750 | 29.9" | 760 | 10-210 | 10 | |||
| 12X800 | 31.5" | 800 | 10-230 | 10 | |||
Applications
Premium Material: Made from 304 or 316 stainless steel for excellent corrosion resistance.
High Tensile Strength: Withstands heavy loads, from 18 lbs (8 kg) to over 120 lbs (54 kg).
Wide Temperature Range: Performs reliably from -100°F to 1000°F (-73°C to 538°C). Reusable & Locking Design: Many models feature a reusable locking mechanism for easy adjustments and maintenance.
Fire & UV Resistant: SNon-flammable and impervious to sunlight degradation.
Packaging Information
1. 100 pcs in 1 plastic bag.
2. 50bag in carton box.
3. Outside carton box Size: 54*32*30 cm, Weight: 21kg.
4. OEM Service available for mass quantity, can print logo on cartons.
Inner Packaging
Outer Carton
-
