SC / FC / LC / ST Hybrid Adapter
Optic Fiber Hybrid Adapter
SC / FC / LC / ST Hybrid Adapter
Product Features
1. High-precision zirconia sleeve and mechanical dimensions.
2. Good reliability & stability.
3. Available in simplex and duplex types4. Available in metal and plastic housing.
4. ITU standard.
5. Fully compliant with ISO 9001:2008 quality management system.
Applications
1. Telecommunication system.
2. Optical communication networks.
3. CATV, FTTH, LAN.
4. Fiber optic sensors.
5. Optical transmission system.
6. Test equipment.
7. Industrial, Mechanical, and Military.
8. Advanced production and testing equipment.
9. Fiber distribution frame, mounts in fiber optic wall mount and mount cabinets.
Technical Specifications
|
Parameters |
SM |
MM |
||
|
PC |
UPC |
APC |
UPC |
|
|
Operation Wavelength |
1310&1550nm |
850nm&1300nm |
||
|
Insertion Loss (dB) Max |
≤0.2 |
≤0.2 |
≤0.2 |
≤0.3 |
|
Return Loss (dB) Min |
≥45 |
≥50 |
≥65 |
≥45 |
|
Repeatability Loss (dB) |
≤0.2 |
|||
|
Exchangeability Loss (dB) |
≤0.2 |
|||
|
Repeat Plug-Pull Times |
＞1000 |
|||
|
Operation Temperature (℃) |
-20~85 |
|||
|
Storage Temperature (℃) |
-40~85 |
|||
Packaging information
SC/APC SX Adapter as a reference.50 pcs in 1 plastic box.
1. 5000 specific adapters in carton box.
2. Outside carton box size: 47*39*41 cm, weight: 15.5kg.
3. OEM service available for mass quantity, can print logo on cartons.
Inner Packaging
Outer Carton
-
